C27 and C32 Generator Set Engines Troubleshooting Page 27

Troubleshooting
RENR9348-01 27
Troubleshooting Section
Troubleshooti
ng without a
Diagnostic Code
i02121176
Alternator
(Charging Problem)
SMCS Code: 1405-035
The connection of any electrical equipment and
the disconnection of any electrical equipment may
cause an explosion hazard which may result in in-
jury or death. Do not connect any electrical equip-
ment or disconnect any electrical equipment in an
explosive atmosphere.
Refer to Special Instruction, REHS0354, “Charging
System Troubleshooting” for the proper testing
procedures.
Probable Causes
•
Alternator drive belts
•
Charging circuit
•
Regulator
•
Alternator
Recommended Actions
Alternator Drive Belts
1. Inspect the condition of the alternator drive belts.
If the alternator drive belts are worn or damaged,
replace the belts.
2. Check the tension on the alternator drive belts.
Adjust the tension, if necessary.
Charging Circuit
Inspect the battery cables, wiring, and connections in
the charging circuit. Clean all connections and tighten
all connections. Replace any faulty parts.
Alternator or Regulator
Verify that the alternator or the regulator is operating
correctly. Refer to Special Instruction, REHS0354,
“Charging System Troubleshooting” for the proper
testing procedures. Repair the alternator or replace
the alternator, as needed.
i02422398
Can Not Reach Top Engine
RPM
SMCS Code: 1915-035
Note: If the pr
oblem occurs during high engine loads
then refer to Troubleshooting, “Low Power/Poor or
No Response to Throttle”.
Probable Causes
•
Diagnostic codes
•
Event codes
•
Throttle signal
•
Intake manifold pressure
•
Fuel supply
•
Air inlet and exhaust system
•
Accessory equipment
•
Specificcond
itions
Recommended
Actions
Diagnostic Codes and Event Codes
Certain diagnostic codes and/or event codes may
cause poor performance. Connect the electronic
service tool
and check for active codes and/or logged
codes. Troubleshoot any codes that are present
before continuing with this procedure.
Throttle Signal
Monitor “Th
rottle Position” on Caterpillar Electronic
Technician (ET). Verify that you can achieve full
throttle. Refer to Troubleshooting, “Speed Control -
Test” for th
e proper troubleshooting procedure.
Intake Manifold P r e ss ure
1. Use Cat ET to monitor the “Fuel Position” and
the “Rated Fuel Limit” during engine operation. If
“Fuel Posi
tion” does not equal “Rated Fuel Limit”
there may be a problem with the engine’s intake
air system. Check for the proper operation of the
following
components:
•
Turbocharger
Refer to Systems Operation/Testing and Adjusting
for specific information.
