Caterpillar 3516B and 3516B High Displacement Engines for Caterpillar Built Machines Troubleshooting Page 15

Troubleshooting
RENR5622 15
Troubleshooting Section
Table 1
Required Service Tools
Part
Number
Description
N/A
4 mm Allen Wrench
6V-2197
Transducer
7X-1171 Transducer Adapter
7X-1695
Cable As
146-4080
Digital Multimeter Gp (RS232)
7X-1710 Multimeter Probes
208-0059
Adapter Cable As (70-PIN BREAKOUT)
7X-6370
Adapter Cable As (3-PIN BREAKOUT)
167-9225
Harness (SERVICE TOOL ADAPTER)
1U-5804
Crimp Tool (12GA TO 18GA)
175-3700
Connector Repair Kit (DEUTSCH DT)
Two short jumper wires are needed to check the
continuity of some wiring harness circuits by shorting
two adjacent terminals together in a connector. A
long extension wire may also be needed to check the
continuity of some wiring harness circuits.
Optional Service Tools
Table 2 lists the optional service tools that may help
you service the engine.
Table 2
Optional S ervice Tools
Part Number Description
198-4240
or
1U-5470
Digital Pressure Indicator
Engine Pressure Group
4C-4075
Crimp Tool (4GA TO 10GA)
4C-4911
(1)
Battery Load Tester
5P-7277
Voltage T ester
6V-9130
(2)
Temperature Adapter (MULTIMETER)
8T-5319
Connector Tool Group
155-5176
AC/DC Current Probe
(1)
Refer to Special Instructions, SEHS9249, “Use of 4C-4911
Battery Load Tester for 6, 8, and 12 Volt Lead Acid Batteries”
and Special Instructions, SEHS7633, “Battery Test Procedure”.
(2)
Refer to Spec ial Instructions, SEHS8382, “Use of the 6V-9130
Temperature A dapter Group”.
Caterpillar Electronic Technician
(ET)
Cat ET can display the following information:
•
Parameters
•
Event codes
•
Diagnostic codes
•
Engine configu
ration
Cat ET can be used by the technician to perform the
following fun
ctions:
•
Diagnostic tests
•
Sensor calibration
•
Flash program
ming
•
Set parameters
Table 3 lists the service tools that are required in
order to use Cat ET.
Table 3
ServiceToolsfortheUseofCatET
Part
Number
Description
N/A Personal Computer (PC)
JERD2124 Single user license for Cat ET
JERD2129
Data Subscription for All Engines and
Machines
171-4400
(1)
Communication Adapter Gp (CAT ET TO
ECM INTERFACE)
237-7547
(2)
Adapter Ca
ble As
(1)
The 7X-1700 Communication Adapter Gp m ay also be used.
(2)
The 237-7547 Adapter Cable As is required to c onnect to the
USB port on computers that are n ot equipped with a RS232
serial port.
Note: For more information regarding the use of
Cat ET and the PC requirements for Cat ET, refer to
the documentation that accompanies your Cat ET
software.
