Caterpillar 3516B and 3516B High Displacement Engines for Caterpillar Built Machines Troubleshooting Page 31

Troubleshooting
RENR5622 31
Troubleshooting Section
Table 11
Diagnostic Codes Table
Description
Conditions wh
ich Generate this Code
System Respon
se
MID 0036 - CID 0268 - FMI 02 Check
Programmable Parameters
The engine’s Electronic Control Module
(ECM) detects that one or more of the
programmable parameters have not
been programmed.
MID 0036 - CID 1495 - FMI 02 Injector
Trim Codes Not Programmed
The engine’s ECM detects that one or
more of the injector trim codes have not
been programmed.
Thecodeisactive.
The ECM may use a default torque map
ortheECMmaylimittheenginetolow
idle.
System configuration parameters are parameters
t
hat affect emissions and power of the engine
applications. Default values for the parameters are
programmed at the factory. Some parameters may
b
e changed by the customer in order to suit the
needs of the specific application. Proper values for
these parameters are available on the electronic
service tool. Certain configuration parameters are
also stamped on the engine information plate.
No password is required for programming a new
Electronic Control Module (ECM) during the first
100 hours of service life. This 100 hour “free
configuration” feature enables the customer to tailor
the programmable setpoints to the requirements
of the installation. Exceptions are “Fuel Limit” and
“Personality Module Mismatch”.
Note: If the parameters that are protected with
the factory passwords are changed, the Caterpillar
warranty may be voided.
