Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 20

Systems Operation Troubleshooting Testing and Adjusting
20 KENR8601
Systems Operation Section
i02897960
Modes O f Operation
SMCS Code: 4490
Table 2
Display Area Functions W h en In Normal Mode, Alarm Mode Or Shutdown Mode
(1)
Item Of Disp lay Area
Normal Mode
(2)
Alarm Mode
(2)
Shutdown Mode
Upper Display
AC Data Shown AC Data Shown
(3)
Fault Code Shown
Lower Display
AC Power Data, Engine Data
And Relay Status Shown
AC Power Data, Engine Data
And Relay Status Show n
AC Power Data, Engine Data
And Relay Status Shown
Shutdown Indicator(s) All Off All Off
Flashing
Fault Alarm Indicator
Off
Flashing
(3)
Off
Key Function Normal Mode Alarm Mode
Shutdown Mod
e
Power M eter Key
Starts And Stops The
Scrolling Of Power Meter
Data On Lower D isplay.
Selects All Power Meter Data
To Be Shown.
Starts And Stops The
Scrolling Of Power Meter
Data On Lower Display.
Selects All Power Meter Data
To Be Shown.
Starts And Stops The
Scrolling Of Power Meter
Data On Lower Display
Selects All Power Meter Data
To B e S h o wn.
AC Select Ke
y
Selects The
AC Data That
Is Shown On The U pper
Display
Selects The
AC Data That
IsShownOnTheUpper
Display
No Function
Engine Mete
rKey
Starts And Stops The
Scrolling Of Engine
Conditions On Lower Displ ay
Starts And Stops The
Scrolling Of Engine
Conditions On Lower Dis play
Starts And Stops The
Scrolling Of Engine
Conditions On Lower Display
Lamp Test Key
Performs A
Lamp Test
Performs A
Lamp Te st
Performs A
Lamp Test
Alarms Code Key
No Function
Shows The Alarm Fault Code
On The Upper Display
No Function
Exit Key
(4)
No Function No Function No Function
Service Mode Key Enters The GSC+P Into
Service Mode
(4)
Enters The GSC+P Into
Service Mode
(5)
No Function
(1)
For a description of the display area functions w hen in Service Mode, refer to Systems Operation, “Service Mode”. For a description of the
display area functions when in Paralleling Mode, refer to Syste ms Operation, “Paralleling Mode”.
(2)
Synchroni
zation Mode is enabled in Normal Mode or Alarm Mode.
(3)
When an alarm fault is present, the alarm fault code is shown on the upper display when the alarm codes key is pressed.
(4)
This key only fun ctions when in service mode, refer to Systems Operation, “Service Mode”.
(4)
Service Mo
de cannot be entered when the E C S is in the AUTOposition.
