Electronic Modular Control Panel II+ Paralleling (EMCP II+P) Page 65

Systems Operation Troubleshooting Testing and Adjusting
KENR8601 65
Systems Operation Section
6. Coolant temperature has exceeded the high
water temperature shutdown setpoint that is
programmed into th e GS C+P.
7. The engine has failed to start(overcrank fault).
8. The engine speed exceeded the engine overspeed
setpoint that is programmed into the GSC+P.
9. The engine is shut down due to a coolant loss
fault.
10. The engine is shut down due to a spare fault.
11. The engine is shut down due to an emergency
stop fault.
12. The engine is shut down due to a diagnostic fault.
The first eight items control the operation of the
indicators and horn. Refer to Table 12 for more
information. The last four items control the operation
of the horn only.
A maximum of three modules (alarm module, C IM,
orRDM)canbeconnectedtotheserialdatalink.
The maximum distance between a module and the
GSC+P is 305 m (1000 ft).
The data link will malfunction under the following
conditions with multiple module s:
•
One of the modules is powered down. “BATT+” or
“BATT-” could be disconnected.
•
The module that is powered down remains
connected to the data link.
Under these conditions the indicators controlled by
the data link of the other module(s) that are powered
up will flash at 0.5 hertz.
Indicator And Horn Operation
Ta bl e 1 2
Indicator And Horn Function
Indicator
Color
NFPA 99 ALM
EMCP RAN
1Amber
High Coolant
Temp A larm
LI,H,LAT,TD
High Coolant Te
mp
Alarm
LI,H,LAT,TD
2Amber
Low Coolant
Temp A larm
LI, H, LAT
Low Coolant Te mp
Alarm
LI, H, LAT
3Amber
Low Oil Press
Alarm
LI, H, LAT
Low Oil Press Al
arm
LI, H, LAT
4 Amber Low Fuel Level
SW(1), H
Not In Auto
LI, H
5 Red Not In Auto
LI, H
High Coolant Temp
Shutdown
(1)
LI,H,TD
6Red
Low DCV
INT, TIM
Low DCV
INT, TIM
7Red
Spare
SW(3)
Overcrank
Shutdown
(1)
LI, H
8Red
Spare
SW(4)
Overspeed
Shutdown
(1)
LI, H
SW(2) Not Used
(1)
Latched by the GSC+P
The above table lists the following abbreviations.
ALM – Alarm Module
H–Horn is sounded.
INT – The signal source is internal to the module.
LAT – “LATCHED” alarm fault
LI – T he data link from the GSC+P is the signal
source.
RAN – Remote Annunciator
SW – One of 4 switches is the signal source. The
number in parentheses indicates which switch is the
signal source.
TD – A 10 second de lay occurs before the fault is
annunciated.
TIM – a 60 second time delay occurs before the fault
is annunciated.
