Engine/Gear Parameters

Governor Type

OEM

Description:

Caterpillar offers three governor options, selectable with

the Governor Type parameter. These three options are

the Full Range Governor, and two types of the Min/Max

Governor.

Full Range Governor

This governor type allows the engine to maintain engine

speed for a given throttle position. The Full Range

Governor is capable of injecting the maximum amount of

fuel for a given desired engine speed.

The Full Range Governor is very sensitive to

changes in engine speed, and is therefore not the

preferred governor type for vehicles using automatic

transmissions. For example, if the ECM wants to

maintain 1500 rpm, the governor will try to maintain

the desired speed. When an automatic transmission

performs an upshift, the actual engine speed will fall

below the desired engine speed of 1500 rpm. The Full

Range Governor would then inject a large amount of

fuel in an attempt to increase the engine speed back

up to the desired engine speed of 1500 rpm. This

causes undesirable, harsh shifting with an automatic

transmission.

Min/Max Governor

The Min/Max Governor, however, is well-suited for

vehicles with automatic transmissions. The Min/

Max governor will only control engine speed when

at the minimum (low idle) or maximum (top engine

limit) allowed engine speed. When in between these

two extremes, the engine will produce the power

proportional to the throttle position. This results

in smoother shifting with automatic/automated

transmissions.

The Min/Max Governor optimizes automatic

transmission shift quality and power modulation,

allowing the operator to adjust the engine power output

to match typical vehicle operating conditions. The

engine speed will vary to ﬁ nd a vehicle load level which

will match the engine power output speciﬁ ed by the

throttle. If the throttle is commanding more power than

the vehicle load will offer, the engine will accelerate

to the top engine limit. This makes it very difﬁ cult to

maintain a constant engine speed when the vehicle is

parked. Slightly depressing the throttle pedal with the

vehicle parked will cause the engine to go to the top

engine limit, which may be undesirable for applications

that require precise engine speed control while parked.

This problem can be solved by the third governor type.
