Cat Undercarriage Management Guide Page 7

Management Guide
7
Be sure your track is always properly adjusted
Every application affects
undercarriage wear differently and
requires proper track adjustment.
Adjust your track in the underfoot
conditions in which your machine is
working. For example, if track that is
correctly adjusted for a non-packing
application is put into a packing
situation, packing materials will
increase track tension, making the
track adjustment too tight. Added
track tension increases both the
load and the wear on all mating
components of your
undercarriage.
Improperly adjusted track can result
in problems and wear on other
components such as:
• Bushing and sprocket wear
Tight track increases loads which
advances wear. Wear occurs as the
bushing rotates and/or slides in
the sprocket.
• Link, track roller, and idler wear
To a lesser extent, tight track
increases loads between the links,
rollers, and idlers. This particularly
accelerates wear on the idlers.
For information on how to adjust
your track, see Track Adjustment
Procedures.
❏ 1. Call your parts and service
representative for expert advice
and service.
❏ 2. Adjust the track for correct tension.
Always adjust track in its working
environment. Correct track adjustment
is
critical.
❏ 3. Tighten the track hardware correctly,
using Caterpillar torque-turn method.
❏ 4. Make daily visual inspections of the
equipment. Check for loose bolts, leaking
seals, and abnormal wear.
❏ 5. Keep the undercarriage clean of mud
and debris so rollers can turn properly.
Operating Checklist
❏ 1. Always use the narrowest shoe possible
which still allows adequate flotation.
❏ 2. Minimize high operating speeds in non-
productive situations, especially in reverse.
❏ 3. Alternate turning direction since turning
only in one direction wears out one side of
the machine faster than the other.
❏ 4. Rotate the track from side to side if you
or your operators tend to work on one side
of the machine more than the other.
❏ 5. Do not spin the tracks since it reduces
production while increasing wear on all
undercarriage components, especially on
grouser bars.
Maintenance Checklist
