Programming Cat Electronic Truck Engine Page 13

Programming
Page 12
Introduction
Feature Comparison by Model
Feature
C-10
C-12
C-15
C-16
3126E
EPA 2004
EPA 2004
EPA 2007
EPA 2007
Lower Gears Turn Off Speed
zzzzzz
Intermediate Gears Engine rpm Limit
zzzzzz
Intermediate Gears Turn Off Speed
zzzzzz
Gear Down Protection rpm Limit
zzzzzz
Gear Down Protection Turn On Speed
zzzzzz
Top Engine Limit
zzzz
Low Idle Engine rpm
zzzzzz
Top Engine Limit with Droop
(only available PM MAR03 and older)
zz
Transmission Style
zzzzzz
Eaton Top 2 Override with Cruise Switch
zzz
Eaton Top 2 Gear Ratios
zzz
AT/MT/HT Part Throttle Shift Speed
zz z
Governor Type (excludes C-10, C-12, C-15, C-16
PM OCT01)
zzzzzz
Transmission Neutral Start Interlock
(GM C7 only)
zz
ARD Programmable Regeneration Monitoring
System
zz
ARD Fan Enable Vehicle Speed Threshold
zz
ARD PTO Mode Stationary Regeneration Enable
zz
Malfunction Indicator Lamp Confi g
(Euro IV)
zz
Data Link ARD Disable
zz
Number of Diesel Particulate Filters
zz
Diesel Particulate Filter #1 & #2 S/N
zz
ARD Fuel Nozzle Cleaner Confi guration
zz
Battery Monitor and Engine Control Voltage
zzzzzz
Engine Emissions Certifi cation
Confi guration (2008 and newer)
zz
Engine Idle Shutdown System
Confi guration (2008 and newer)
zz
Cold Mode Idle Shutdown Timer Enable (2008
and newer)
zz
Engine Idle Shutdown Timer Reset Enable (2008
and newer)
zz
Idle Shutdown Timer
zzzzzz
Idle Shutdown Timer Maximum RPM
zzz
Allow Idle Shutdown Override
zzzzzz
Idle Shutdown Ignore Neutral Switch
zz
Minimum Idle Shutdown Outside Temp
zzzzzz
Maximum Idle Shutdown Outside Temp
zzzzzz
A/C Switch Fan-On Time
zzzzzz
