Programming Cat Electronic Truck Engine Page 207

Programming
Page 206
PTO Switch On Lamp
Description:
The PTO Switch On Lamp parameter is used to enable
a lamp output when programmed to the Default value
listed below. This lamp is enabled whenever the PTO
switch is closed, but is not available when the Warning
Lamp parameter is programmed to Option 1.
Available:
3126E, C7, C9 medium-duty engines and all EPA’07 and
newer On-Highway Engines
Range:
Engine Range Default
Pre-2007 None J1/P1:30
EPA’07 and
newer C7,
C9, C13 &
C15
J1/P1: 10, 11,
12, 13, 19, 20
High Side Driver
(2 Amp Output)
None
J1/P1: 29, 30, 31
Low Side Driver
(Sensor Common)
Note: The PTO Switch On Lamp Output is part of the
Caterpillar Multi I/O System. Both High Side (2 Amp
Output) or Low Side (Sensor Common) Drivers can
be programmed. Failure to properly program the
PTO Switch On Lamp Output could cause undesired
operation or damage to chassis components.
Advantages:
This parameter provides enables a lamp that will notify
the truck operator when the engine is in PTO mode.
Output Selection
