Programming Cat Electronic Truck Engine Page 14

Programming
Page 13
Introduction
Feature Comparison by Model
Feature
C-10
C-12
C-15
C-16
3126E
EPA 2004
EPA 2004
EPA 2007
EPA 2007
Engine Retarder Delay
zzzz
Engine Monitoring Mode
zzzzzz
Engine Monitoring Lamps
zzzz
Warning Lamp Confi g (Red Stop Lamp)
zz
Coolant Level Sensor
zzzzzz
Low Coolant Level Lamp
zz
High Coolant Temperature Lamp
zz
Coolant Temperature Derate
zz
Low Oil Pressure Lamp
zzzz
Oil Level Switch Installation Status
(GMT560 with 3126 & C9 only)
zz
Maintenance Indicator Mode
zzzzzz
PM1 Interval
zzzzzz
Engine Oil Capacity
zzzzzz
Fuel Correction Factor
zzzz
Change Fuel Correction Factor
(Dash Access)
zzzz
PM1 Reset (Dash Access)
zzzzzz
Fleet Trip Reset (Dash Access)
zzzz
Customer Parameters (Dash Access)
zz z
State Selection (Dash Access)
zzzz
Vehicle Overspeed Threshold
zz
Theft Deterrent
zzzzzz
Theft Deterrent Password
zzzzzz
Quick Stop Rate
zzzzzz
Minimum Idle Time
zz
Driver Reward Enable
z
Fan Control Type
zzzzzz
Fan Pulley Ratio
zz
Fan with Engine Retarder in High Mode
zzzzzz
Number of Cooling Fan Blades
zz
Cooling Fan Diameter
zz
Minimum Fan Speed
zz
Maximum Fan Speed
zz
Maximum Fan Speed Ratio Multiplier
zz
Primary Fuel Tank Capacity
(GMT560 with 3126 & C9 only)
zzzz
Secondary Fuel Tank Capacity
(GMT560 with 3126 & C9 only)
zz z
Customer Passwords #1 & #2
zzzzzz
