Programming Cat Electronic Truck Engine Page 196

Programming
Page 195
Input Selection
Air Inlet Shutoff Switch /
OEM
/
Description:
This parameter identifi es the switch input to be used to
manually force the Air Inlet Shutoff system to operate,
causing the engine to shutdown.
An Air Inlet Shutoff Override Switch input can be used to
test the function of the Inlet Air Shutoff System. Closing
this switch input, with the Transmission in Neutral
and with zero vehicle speed, will cause the solenoid
controlling the Inlet Air Shutoff System to actuate. The
Air Inlet Shutoff Override Switch is programmable to one
of several ECM terminal locations.
Available:
EPA’07 and newer C7, C9, C13 & C15 on-highway engines
Range:
Engine Range
Cat
Default
EPA’07 and
newer C7, C9,
C13 & C15
None
J1/P1: 6, 7, 22, 23, 35, 40, 44,
45, 46, 47, 56, 58, 59, 60
None
