Programming Cat Electronic Truck Engine Page 141

Programming
Page 140
Dash Display Access Parameter
PM1 Reset
Description:
This parameter allows the reset of the PM1
Maintenance via the Caterpillar Driver Information
Display (Cat ID) or Cat Messenger. A properly
installed Cat ID or Cat Messenger is required and
the Maintenance Indicator Mode parameter must be
programmed to either of the Manual or Automatic
Modes.
Options are:
No - Can not reset Maintenance Indicator from Cat ID
or Cat Messenger
Yes - May reset Maintenance Indicator from Cat ID or
Cat Messenger
Available:
All electronically-controlled engines covered in this
handbook
Range:
Range Cat Default
No
Yes
No
Advantages:
For those who have a Caterpillar Driver Information
Display or Cat Messenger and are using one of the
Maintenance Indicator Modes this feature allows the
resetting of the Maintenance Indicator without a service
tool.
Disadvantages:
If the PM is accidently reset from the Dash Display, the
oil change interval could be exceeded.
Recommendations:
✔ Program this parameter to No unless this feature is
desired by the driver or fl eet owner.
✔ This programmable feature is application
dependant and should be programmed based on
customer specifi c requirements.
