Programming Cat Electronic Truck Engine Page 182

Programming
Page 181
Input Selection
Cruise Control Pause Switch /
OEM
/
Description:
The Cruise Control Pause Switch parameter is
programmed to identify the Cruise Control Pause Switch
connection to the ECM. If this parameter is programmed
to J1939 Body Controller, Instrument Cluster, or Cab
Controller, the Cruise Control Pause Switch will act like
the service brake or clutch switch by causing the PTO
mode to kickout. If in the On position, the switch will
prevent the engine from entering PTO mode, and there is
no programmable parameter for ignoring this switch.
Available:
3126E, C7, C9, C-10, C-12, C-15, C-16 (PM JAN02 and
after) C11, C13, C15
Range:
Engine Alternatives Default
Pre-2007
J1939 Body Controller,
J1939 Cab Controller,
J1939 Instrument Cluster
None
EPA’07 and
newer C7,
C9, C13, C15
J1939 Body Controller,
J1939 Cab Controller,
J1939 Instrument Cluster
J1939 Cab Display
None
Recommendations:
✔ Make sure that the vehicle is equipped with a J1939
data link if programming this parameter to one of
the J1939 source Alternatives. Failure to do so will
generate a diagnostic code.
