Programming Cat Electronic Truck Engine Page 188

Programming
Page 187
Input Selection
Starting Aid On/Off Switch /
OEM
/
Description:
The Starting Aid On/Off Switch parameter is
programmed to identify the type of connection the
Starting Aid On/Off Switch has with the ECM. The
Starting Aid On/Off Switch is used to allow the operator
to enable or disable the ECM controlled Starting Aid
Output. If the switch is in the On position, the ECM will
automatically enable the Starting Aid Output when
conditions require the use of a starting aid. When the
switch is in the Off position, the Starting Aid system will
not function.
Available:
C-10, C-12, C-15, C-16, C11, C13, C15 heavy duty engines
and all EPA’07 On-Highway Engines
Range:
Engine Alternatives Default
Pre-2007 J1/P1:6, J1/P1:7, J1/P1:46, J1/P1:47 None
EPA’07
J1/P1: 6, 7, 22, 23, 35, 40, 44, 45, 46,
47, 56, 58, 59, 60
None
