Trip Parameters
Theft Deterrent Password
Description:
The Theft Deterrent password is required if the Theft
Deterrent parameter (see previous page) is programmed
to Yes. This password is then required to restart the
engine if the Theft Deterrent feature has been enabled
before the engine was shutdown. If the Theft Deterrent
Password is lost or forgotten a service tool is required to
start the engine.
Available:
All electronically controlled on-highway engines
covered in this handbook
Range:
Range Default
Four Characters
A thru Z, 0 thru 9
0000
(All Zeros)
Note: Alphabetic characters must be UPPER CASE
Advantages:
The Theft Deterrent can be an effective method to
control unauthorized operation of the vehicle.
Disadvantages:
If the password is forgotten, the truck will be out of
service. The password can be obtained using a service
tool.
Recommendations:
✔ Caterpillar recommends using the Theft Deterrent
System.
✔ With a choice of all alphanumeric characters
a password can be selected that is easily
remembered.
