Accelerator Control (28)

Accelerator Control - Push down on the

accelerator pedal in order to increase engine

speed. Release the accelerator pedal in

order to decrease engine speed. The

accelerator pedal will return to the setting of

the governor control.

Interlock Control (29)

Interlock Control - Move the armrest to the RAISED position in order to lock out the hydraulic controls.

Note: When the armrest is moved to the RAISED position, the parking brake will engage. Move the armrest

to the LOWERED position and push the switch for the parking brake in order to activate the hydraulic

controls.

Note: When you start the engine, the parking brake must be disengaged in order for the hydraulic controls

to be activated. If the armrest is raised and then lowered during operation, you must disengage the parking

brake in order for the hydraulic controls to be activated.

Machine Security System (If Equipped)

NOTICE

This machine is equipped with a Caterpillar Machine

Security System (MSS) and may not start under certain

conditions. Read the following information and know your

machine's settings. Your Caterpillar Dealer can identify

your machine settings.

Machine Security System (MSS) -

Machines that are equipped with a

Caterpillar Machine Security System (MSS)

can be identified by a decal in the operator

station. MSS is designed to prevent theft of

the machine or unauthorized operation.

Basic Operation

MSS may be programmed to read a standard Caterpillar key or an electronic key. The electronic key

contains an electronic chip within the plastic housing for the key. Each key emits a unique signal to the

MSS. The keys can be identified by a gray housing or a yellow housing. MSS can have programmed settings

to require an electronic key or a standard Caterpillar key for starting during certain periods of time.

When the key start switch of the machine is turned to the ON position, the ECM will read the unique ID that

118
