b. Fasten the seat belt and lower the armrest.

c. Start the engine.

d. Disengage the parking brake.

e. Keep the work tool close to the ground.

f. Activate the tilt control in order to tilt the work tool downward.

g. Apply down pressure on the work tool.

Note: The work tool Operation and Maintenance Manual will inform you if forward pressure

should not be applied on a work tool.

h. Move the machine backward. Ensure that the coupler pins do not disengage from the work tool.

18. Test the work tool for leaks and for proper operation.

Removing the Work Tool

Disengaging the coupler pins will release the work tool from

control of the operator.

Serious injury or death may result from disengaging the

work tool when it is in an unstable position or carrying a

load.

Place the work tool in a safe position before disengaging

the coupler pins.

NOTICE

Auxiliary hoses for work tools must be disconnected before

the quick coupler is disengaged.

Pulling the work tool with the auxiliary hoses could result

in damage to the host machine or the work tool.

1. Position the machine on level ground.

2. Lower the work tool to the ground.

3. Rack back the work tool until the work tool is slightly off the ground.

4. Turn the engine start switch key to the OFF position in order to stop the engine.

5. If the work tool requires hydraulics the hydraulic system pressure must be released. Refer to the

section "Releasing the Auxiliary Hydraulic System Pressure".

146
