CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 330

Operation and Maintenance Manual

Page of 331

/ 331

O - The machine performance is optimum with this work tool.

A - The machine performance is acceptable with this work tool.

HF - The machine is equipped with high flow hydraulics.

NR - This work tool is not recommended for use on this machine.

! - This work tool is not approved for use on this machine.

* - This work tool has a lift restriction on this machine. Do not raise the lower pivot pin higher than 1 m (3

ft) above the ground.

Many of the work tools in the table have an Operation and Maintenance Manual. Please refer to the

Operation and Maintenance Manual that is provided with the work tool for the proper use of the work tool.

Contact your Caterpillar dealer concerning specific work tools that are approved by Caterpillar for this

machine. This list was complete at the time of publication. There may be additional work tools that have

been approved since that time. Consult your Caterpillar dealer for an updated list of approved work tools.

INTENDED USE STATEMENT FOR THE GRAPPLE RAKE

This Work Tool has the intended functions of raking, loading, carrying, and moving bulky material. The

material may be encountered in the following applications:

Landscape cleanup

Storm debris cleanup

Demolition

Industrial

Construction
