CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 221

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i01743875

Bucket Cutting Edges - Inspect/Replace

SMCS - 6801-040; 6801-510

Personal injury or death can result from bucket falling.

Block the bucket before changing bucket cutting edges.

1. Lower the lift arms fully. Tilt back the bucket so that the bucket cutting edge is accessible.

2. Place blocks under the raised edge of the bucket.

3. Remove the bolts. Remove the cutting edge and the end bits.

4. Clean the contact surfaces.

5. Use the opposite side of the cutting edge, if this side is not worn.

6. Install a new cutting edge, if both edges are worn.

7. Install the bolts.

8. Remove the blocks that are under the bucket.

9. After a few hours of operation, check the bolts for proper torque.
