CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 51

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i02780235

Slope Operation

SMCS - 7000

Machines that are operating safely in various applications depend on these criteria: the machine model,

configuration, machine maintenance, operating speed of the machine, conditions of the terrain, fluid levels

and tire inflation pressures. The most important criteria are the skill and judgment of the operator.

A well trained operator that follows the instructions in the Operation and Maintenance Manual has the

greatest impact on stability. Operator training provides a person with the following abilities: observation of

working and environmental conditions, feel for the machine, identification of potential hazards and

operating the machine safely by making appropriate decisions.

When you work on side hills and when you work on slopes, consider the following important points:

Speed of travel - At higher speeds, forces of inertia tend to make the machine less stable.

Roughness of terrain or surface - The machine may be less stable with uneven terrain.

Direction of travel - Avoid operating the machine across the slope. When possible, operate the machine

up the slopes and operate the machine down the slopes. Place the heaviest end of the machine uphill when

you are working on an incline.

Mounted equipment - Balance of the machine may be impeded by the following components: equipment

that is mounted on the machine, machine configuration, weights and counterweights.

Nature of surface - Ground that has been newly filled with earth may collapse from the weight of the

machine.

Surface material - Rocks and moisture of the surface material may drastically affect the machine's

traction and machine's stability. Rocky surfaces may promote side slipping of the machine.

Slippage due to excessive loads - This may cause downhill tracks or downhill tires to dig into the

ground, which will increase the angle of the machine.

Width of tracks or tires - Narrower tracks or narrower tires further increase the digging into the ground

which causes the machine to be less stable.

Implements attached to the drawbar - This may decrease the weight on the uphill tracks. This may

also decrease the weight on the uphill tires. The decreased weight will cause the machine to be less stable.

Shutdown SIS

Previous Screen
