CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 191

Operation and Maintenance Manual

Page of 331

/ 331

Product: SKID STEER LOADER

Model: 226B SKID STEER LOADER MJH

Configuration: 216B 226B 232B 242B Skid Steer Loader MJH00001-10574

(MACHINE) POWERED BY 3024C Engine

Operation and Maintenance Manual

216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B and 268B Skid Steer Loaders

Media Number -SEBU7731-08 Publication Date -01/07/2007 Date Updated -16/07/2007

i02015033

Cab Tilting

SMCS - 7301-506; 7301-509

Do not go beneath cab unless cab is empty and support

lever is engaged.

Failure to follow the instructions or heed the warnings

could result in injury or death.

Do not tilt the cab using an open door. The door must be

closed and latched when lifting the cab. The door may

become dislodged from its hinges and may cause serious

personal injury or death.

Tilting the Cab Upward

1. Park the machine on level ground.

Note: Empty the water tank (if equipped) before you tilt the cab.

2. Lower the loader arms fully. If you tilt the cab upward with the loader lift arms in the RAISED

position, you must engage the brace for the loader lift arms. See Operation and Maintenance Manual,

"Loader Lift Arm Brace Operation" for the process for engaging the brace for the loader lift arms.

3. Turn the engine start switch key to the OFF position.

4. Place supports under the rear of the machine in order to support the machine while the cab is tilted.

Shutdown SIS

Previous Screen

190
