CAT 226B SKID STEER LOADER MJH Operation and Maintenance Manual Page 35

Operation and Maintenance Manual

Page of 331

/ 331

Do not operate a machine with a fluid leak. Repair leaks and clean up fluids before resuming machine

operation. Fluids that are leaking or spilled onto hot surfaces or onto electrical components can cause a fire.

A fire may cause personal injury or death.

Remove flammable material such as leaves, twigs, papers, trash, etc. These items may accumulate in the

engine compartment or around other hot areas and hot parts on the machine.

Keep the access doors to major machine compartments closed and access doors in working condition in

order to permit the use of fire suppression equipment, in case a fire should occur.

Clean all accumulations of flammable materials such as fuel, oil and debris from the machine.

Do not operate the machine near any flame.

Keep shields in place. Exhaust shields (if equipped) protect hot exhaust components from oil spray or fuel

spray in case of a break in a line, in a hose, or in a seal. Exhaust shields must be installed correctly.

Do not weld or flame cut on tanks or lines that contain flammable fluids or flammable material. Empty and

purge the lines and tanks. Then clean the lines and tanks with a nonflammable solvent prior to welding or

flame cutting. Ensure that the components are properly grounded in order to avoid unwanted arcs.

Dust that is generated from repairing nonmetallic hoods or fenders may be flammable and/or explosive.

Repair such components in a well ventilated area away from open flames or sparks. Use suitable Personal

Protection Equipment (PPE).

Inspect all lines and hoses for wear or deterioration. Replace damaged lines and hoses. The lines and the

hoses should have adequate support and secure clamps. Tighten all connections to the recommended

torque. Damage to the protective cover or insulation may provide fuel for fires.

Store fuels and lubricants in properly marked containers away from unauthorized personnel. Store oily rags

and flammable materials in protective containers. Do not smoke in areas that are used for storing

flammable materials.
