Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 121

OPERATORS MANUAL
TM 5-3805-261-10
0011 00-1
TROUBLESHOOTING PROCEDURES 0011 00
MALFUNCTION TEST OR INSPECTION CORRECTIVE ACTION
EMS FAULT INDICATORS
1. EMS Coolant Temp Indicator Flashes
During Operation.
WARNING
• DO NOT service cooling system unless engine has been
allowed to cool down. This is a pressurized cooling system and
escaping steam or hot coolant will cause serious burns.
• DO NOT remove cooling system radiator cap when engine is
hot. Allow engine to cool down. Failure to follow this warning
may cause serious burns.
• Wear effective eye, glove, and skin protection when handling
coolants. Failure to follow this warning may cause injury to
personnel.
1. Check for flashing coolant
temperature indicator during
operation.
Reduce load and continue to
monitor temperature. If indicator
is still flashing, go to test step 2.
2. Allow engine to idle at 960
RPM for 5-10 minutes to cool
down.
If problem still exists shut down
engine and, go to test step 3.
3. Check radiator for debris. Remove debris. If there is
excessive debris, notify Unit
Maintenance. If no debris is
present, go to test step 4.
4. Check system for leaks. If leaks are found, notify Unit
Maintenance. If no leaks are
found, go to test step 5.
5. Check coolant level. If low, add coolant (WP 0013 00).
If coolant level is okay, go to test
step 6.
6. Check water pump and fan
drive belts for looseness and/or
damage.
If water pump and fan drive belts
are loose and/or damaged, notify
Unit Maintenance. If belts are
okay, go to test step 7.
7. Check engine oil level. If engine oil is low, fill to correct
level (WP 0013 00). If problem
still exists, go to test step 8.
