Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 255

OPERATORS MANUAL
TM 5-3805-261-10
EXPENDABLE AND DURABLE ITEMS LIST - CONTINUED 0022 00
0022 00-3
8 C GREASE: Automotive and Artillery GAA
9150-01-197-7688 (81349) M-10924-A
1-1/4 Ounce Tube TU
9150-01-197-7693 (81349) M-10924-B
14 Ounce Cartridge CA
9150-01-197-7690 (81349) M-10924-C
1-3/4 Pound Can CN
9150-01-197-7692 (81349) M-10924-E
35 Pound Can CN
9 C 9150-00-543-7220 Lubricating Oil: Molybdenum Disulfied,
Silicone (81349) DOD-L-25681
LB
10 C OIL: Lubricating, Arctic, OEA
9150-00-402-4478 (81349) MIL-L-46167
1 Quart Can CN
9150-00-402-2372 (81349) MIL-PRF-46167
5 Gallon Can CN
9150-00-491-7197 (81349) MIL-PRF-46167
55 Gallon Drum DR
11 C OIL: Lubricating, OE/HDO 10
(81349) MIL-PRF-2104
9150-00-189-6727
9150-00-186-6668
9150-00-191-2772
1 Quart Can
5 Gallon Can
55 Gallon Drum
CN
CN
DR
12 C 9150-00-247-0481 OIL: Lubricating, OE/HDO 10W/30
(81349) MIL-L-2104
QT
13 C OIL: Lubricating, OE/HDO 15W/40
(81349) MIL-PRF-2104
9150-01-152-4117
9150-01-152-4118
9150-01-152-4119
1 Quart Can
5 Gallon Can
55 Gallon Drum
CN
CN
DR
14 C OIL: Lubricating, OE/HDO 30
(81349) MIL-PRF-2104
9150-00-186-6681
9150-00-188-9858
1 Quart Can
5 Gallon Can
CN
CN
(1)
ITEM
NUMBER
(2)
LEVEL
(3)
NATIONAL
STOCK NUMBER
(4)
DESCRIPTION, CAGEC,
AND PART NUMBER
(5)
U/M
