Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 167

OPERATORS MANUAL
TM 5-3805-261-10
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) - CONTINUED 0013 00
0013 00-23
66
(Con’t)
NOTE
• Place portable fire extinguisher within reach prior to refuel-
ing.
• DO NOT overfill fuel tank. If fuel starts foaming from fuel
tank, stop IMMEDIATELY to avoid fuel spillage.
b. Check fuel tank filler tube and cap
for damage or leaks.
Class III fuel leaks or damage
are noted.
c. Remove fuel tank filler cap.
Inspect cap gasket for damage.
Fuel cap gasket is missing or
damaged.
d. Add fuel (Item 5, 6 or 7, WP 0022
00) to tank. DO NOT overfill. Rein-
stall fuel cap and secure.
67 After Radiator
WARNING
• DO NOT service cooling system unless engine has been
allowed to cool down. This is a pressurized cooling system
and escaping steam or hot coolant will cause serious burns.
• DO NOT remove cooling system radiator cap when engine is
hot. Allow engine to cool down. Loosen cap to first stop and let
any pressure out of cooling system, then remove cap. Failure to
follow this warning may cause serious burns.
• Wear effective eye, glove, and skin protection when handling
coolants. Failure to do so may cause injury to personnel.
NOTE
If there is an accumulation of debris at hydraulic oil cooler
and radiator, engine grille must be removed to allow a thor-
ough cleaning. Notify Unit Maintenance.
ITEM
NO. INTERVAL
MAN-
HOURS
LOCATION
ITEM TO
CHECK/
SERVICE PROCEDURE
NOT FULLY MISSION
CAPABLE IF:
