Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 131

OPERATORS MANUAL
TM 5-3805-261-10
TROUBLESHOOTING PROCEDURES - CONTINUED 0011 00
0011 00-11
HYDRAULIC SYSTEM - CONTINUED
2. Blade Drifts After Control Lever Is
Released or Centered.
1. Check blade hydraulic lift
cylinders for damage.
If any damage is found, notify
Unit Maintenance. If no damage
is found and problem still exists,
go to test step 2.
2. Check control linkage for
damage or debris that would
restrict freedom of movement
and/or automatic return to hold
position.
Clean any debris. If any damage
is found, notify Unit
Maintenance.
3. Travel Time of Blade Lift Cylinders Is
Excessively Slow.
1. Check blade hydraulic lift
cylinders for any buildup of
debris.
Clean any debris from
cylinder(s). If problem still
exists, go to test step 2.
2. Check hydraulic oil level. If hydraulic oil level is low, fill to
correct level (WP 0013 00). If
problem still exists, go to test step
3.
3. Check control linkage for
damage or debris that would
restrict freedom of movement
and/or automatic return to hold
position.
Clean any debris from linkage. If
any damage is found, notify Unit
Maintenance.
4. Scarifier Control Lever Binds. 1. Check for bent or damaged
lever.
If lever is bent or damaged, notify
Unit Maintenance. If lever is
okay, go to test step 2.
2. Check control linkage for
damage or debris that would
restrict freedom of movement
and/or automatic return to hold
position.
Clean any debris from linkage. If
any damage is found, notify Unit
Maintenance.
5. Travel Time of Scarifier Is Excessively
Slow.
1. Check scarifier area for any
buildup of debris.
Clean any debris from scarifier
area. If problem still exists, go to
test step 2.
2. Check hydraulic oil level. If hydraulic oil level is low, fill to
correct level (WP 0013 00). If
problem still exists, go to test step
3.
3. Check control linkage for
damage or debris that would
restrict freedom of movement
and/or automatic return to hold
position.
Clean any debris from linkage. If
any damage is found, notify Unit
Maintenance.
MALFUNCTION TEST OR INSPECTION CORRECTIVE ACTION
Previous page
Next page
