Caterpillar GRADER, ROAD, MOTORIZED, DIESEL ENGINE DRIVEN (DED), HEAVY, COMMERCIAL CONSTRUCTION EQUIPMENT (CCE) OPERATORS MANUAL Page 145

OPERATORS MANUAL
TM 5-3805-261-10
0013 00-1
PREVENTIVE MAINTENANCE CHECKS AND SERVICES (PMCS) 0013 00
.
ITEM
NO. INTERVAL
MAN-
HOURS
LOCATION
ITEM TO
CHECK/
SERVICE PROCEDURE
NOT FULLY MISSION
CAPABLE IF:
NOTE
• Review all WARNINGs, CAUTIONs, and NOTEs before
performing PMCS and operating the machine.
• Perform all PMCS checks if:
a. You are the assigned operator but have not operated the
machine since the last weekly checks.
b. You are operating the machine for the first time.
• Unless otherwise indicated, perform PMCS with machine
parked on level ground, parking brake applied, transmission in N
(Neutral), blade lowered to the ground, wheels blocked, and
engine shut down.
• If leakage is detected during performance of PMCS, further
investigation is required to determine location and cause of leak.
• Walk around machine and look for any obvious leaks or dam-
age.
• During walk around, also visually check tires for low infla-
tion, damage, and debris.
LEFT SIDE
AND REAR
1 Before Overall View Check left front side of machine for
evidence of leakage or damage.
Class III leaks or damage that
would impair operation are
evident.
2 Before Lights Check left front work light, head-
lights, front turn signal lights, and
blackout light for missing or damaged
components.
Missing or damaged compo-
nents if necessary for mission.
3 Before Below
Operator
Compart-
ment
Check hoses, cables, and connections
below left side of operator compart-
ment for damage or leaks.
Class III leaks or damage that
would impair operation.
