Crushing Prevention and Cutting Prevention
i01359666
Crushing Prevention and
Cutting Preve
ntion
SMCS Code: 1000; 4450; 7405
Support the component properly when work beneath
the component is performed.
Unless other maintenance instructions are provided,
never attempt adjustments while the engine is
running.
Stay clear of all rotating parts and of all moving
parts. Leave
the guards in place until maintenance
is performed. After the maintenance is performed,
reinstall the guards.
Keep objects away from moving fan blades. The fan
blades will throw objects or cut objects.
When objects are struck, wear protective glasses in
order to avoid injury to the eyes.
Chips or other debris may fly off objects when objects
are struck. Before objects are struck, ensure that no
one will be i
njured by flying debris.
i01372247
Moun ting and Dismounting
SMCS Code: 1000; 4450; 7405
Inspect the steps, the handholds, and the work area
before mounting the engine. Keep these items clean
and keep these items in good repair.
Mount the engine and dismount the engine only at
locations that have steps and/or handholds. Do not
climb on the engine, and do not jump off the engine.
Face the engine in order to mount the engine or
dismount the engine. Maintain a three-point contact
with the steps and handholds. Use two feet and one
hand or use one foot and two hands. Do not use any
controls as handholds.
Do not stand on components which cannot support
your weight. Use an adequate ladder or use a work
platform. Secure the climbing equipment so that the
equipment will not move.
Do not carry tools or supplies when you mount the
engine or when you dismount the engine. Use a hand
line to raise and lower tools or supplies.
i01805780
Before Starting Engine
SMCS Code: 1000
NOTICE
For initial start-up of a new or rebuilt engine, and for
start-up of an
engine that has been serviced, make
provision to shut the engine off should an overspeed
occur. This may be accomplished by shutting off the
air and/or fue
l supply to the engine.
Overspeed shutdown should occur automatically.
If automatic s
hutdown does not occur, press the
emergency stop button in order to cut the fuel and/or
air to the engine.
Inspect the engine for potential hazards.
Before start
ing the engine, ensure that no one is on,
underneath, or close to the engine. Ensure that the
area is free of personnel.
If equipped, ensure that the lighting system for the
engine is suitable for the conditions. Ensure that all
lights work
properly, if equipped.
All protective guards and all protective covers must
be installe
d if the engine must be started in order
to perform service procedures. To help prevent an
accident that is caused by parts in rotation, work
around the p
arts carefully.
Do not bypass the automatic shutoff circuits. Do not
disable th
e automatic shutoff circuits. The circuits are
provided in order to help prevent personal injury. The
circuits are also provided in order to help prevent
engine dam
age.
See the Service Manual for repairs and for
adjustmen
ts.
i02136012
Engine Starting
SMCS Code: 1000
If a warning tag is attached to the engine start switch
or to the controls, DO NOT start the engine or move
the controls. Consult with the person that attached
the warning tag before the engine is started.
All protective guards and all protective covers must
be installed if the engine must be started in order
to perform service procedures. To help prevent an
accident that is caused by parts in rotation, work
around the parts carefully.
