Cold start stra
tegy
•
Automatic air/fuel ratio control
•
Integrated ether start
•
Torque rise sh
aping
•
Automatic altitude compensation
•
Injection timing control
•
System diagno
stics
For more information on electronic engine features,
refer to the Op
eration and Maintenance Manual,
“Features and Controls” topic (Operation Section).
Engine Cooling and Lubrication
Thecoolings
ystem consists of the following
components:
•
Gear-driven
centrifugal water pump
•
Wa ter temperature regulators which regulate the
engine coola
nt temperature
•
Gear-driven oil pump (gear type)
•
Oil cooler
The engine lu
bricating oil is also filtered. Bypass
valves provide unrestricted flow of lubrication oil
to the engine components during the following
conditions
:
•
High oil viscosity
•
Plugged oil cooler or plugged oil filter elements
(paper cartridge)
Engine Service Life
Engine effic
iency and maximum utilization of engine
performance depend on the adherence to proper
operation and maintenance recommendations. In
addition, u
se recommended fuels, coolants and
lubricants. Use this Operation and Maintenance
Manual as a guide for required engine maintenance.
Expected engine life is generally predicted by the
average power that is demanded. The average power
that is dem
anded is based on fuel consumption of the
engine over a period of time. For more information,
refer to the Operation and Maintenance Manual,
“Overhau
l Considerations” topic (Maintenance
Section).
Engine Specific
ations
Note: The front end of the engine is opposite the
flywheel end of
the engine. The left and the right sides
of the engine are determined from the flywheel end.
The number 1 cylinder is the most forward cylinder.
g00291566
Illustration 16
Cylinder and valve locations
(A) Inlet valves
(B) Exhaust valves
Table 1
C27 and C32 Generator Set Engine Specifications
C27 C32
Cylinders and
Arrangement
12 cylinder vee block
Bore 137.7 mm
(5.4 inch)
145 mm
(5.7 inch)
Stroke
152.4 mm
(6 inch)
162 mm
(6.4 inch)
Compression
Ratio
16.5:1 15:1
Aspiration TA
(1)
Displacement
27 L (1648 in
3
) 32 L (1953 in
3
)
Firing Order 1-10-9-6-5-12-11-4-3-8-7-2
Rotation
(flywheel end)
Counterclockwise
(1)
Turbocharged Aftercooled
Generator Description
The SR4B brushless generator is used with the
following loads: mixed loads of motors and lights,
SCR-cont
rolled equipment, computer centers,
installations of communications, and petroleum
drilling applications. The elimination of the brushes in
the field c
ircuit reduces maintenance. The elimination
of the brushes in the field circuit increases reliability.
The elimination of brushes provides a higher degree
of protec
tion in potentially hazardous atmospheres.
