C32 Power Module Operation and Maintenance Manual Page 35

Operation and Maintenance Manual
SEBU8219-01 35
Product Information Section
Product Identification Information
g00776690
Illustration 31
i02331504
Reference Information
SMCS Code: 1000; 4450
Identification of the items in Table 2 may be needed
in order to obtain parts and service. Some of the
numbers are on the engine Serial Number Plate
and/or Information Plate. Locate the information
for your engine. Record the information on the
appropriate space in Table 2. Make a copy of this
list for a record. Retain the information for future
reference.
The top level part numbers in the Parts Manual for
the en
gine are listed with the engine arrangement
number. Occasionally, an arrangement may be
slightly modified before the product is shipped from
the f
actory. In these cases, a modification number
indicates that the arrangement has been modified.
The p
ackaging arrangement may also be called a
pricing arrangement or a customer arrangement. This
is the total package with attachments and options
that
are not included in the engine arrangement.
