Fuel System

i02486828

Fuel System - Inspect

SMCS Code: 1250-040

A problem with the components that send fuel to

the engine can cause low fuel pressure. T his can

decrease engine performance.

1. Check the fuel level in the fuel tank. Ensure that

the vent in the fuel cap is not ﬁ lle d with dirt.

2. Check all fuel lines for fuel leakage. The fuel lines

must be free from restrictions and faulty bends.

Verify that the fuel return line is not collapsed.

3. Install a new fuel ﬁ lter.

4. Cut the old ﬁlter open with the 175 -75 46 Oil

Filter Cutter Gp. Inspect the ﬁlter for exce ss

contamination. Determine the source of the

contamination. Make the necessary repairs.

5. Service the primary fuel ﬁlter (if equipped).

6. Operate the hand priming pump (if equipped).

If excessive resistance is felt, inspect the fuel

pressure regulating valve. If uneven resistance is

felt, test for air in the fuel. Refer to Testing and

Adjusting, “Air in Fuel - Test” for more information.

7. Remove any air tha t may be in the fuel system.

Refer to Testing and Adjusting, “Fuel System -

Prime”.

i02486845

Air in Fuel - Test

SMCS Code: 1280-081

This procedure checks for air in the fuel. This

procedure also assists in ﬁnding the source of the air.

1. Examine the fuel system for leaks. Ensure that

the f uel line ﬁttings are properly tightened. Check

the fuel level in the fuel tank. Air can enter the

fuelsystemonthesuctionsidebetweenthefuel

transfer pump and the fuel tank.

2. Install a 2P-8278 Tube As (SIGHT GA UGE) in

the fuel return line. When possible, install the sight

gauge in a s traight section of the fuel line that is

at least 304.8 mm (12 inches) long. Do not install

the sight gauge near the following devices that

create turbulence:

•

Elbows

•

Relief valves

•

Check valves

Observe the fuel ﬂow during engine cran king.

Look for air bubbles in the fuel. If there is no fuel

in the sight gauge, prime the fuel system. Refer

to Testin g and Adjusting, “Fuel Sy ste m - Prime ”

for more information. If the engine starts, check

for air in the fuel at varying en gine speeds. When

possible, operate the engine under the conditions

which have been suspect of air in the fuel.

g010966

Illustration 21

2P-8278 Tube As (SIGHT GAUGE)

(1) A ste

ady stream of small bubbles with a diameter of

approxi

mately 1.60 mm (0.063 inch) is an acceptable amount

of air in

the fuel.

(2) Bubb

les with a diameter of approximately 6.35 mm ( 0.250 inch)

are also

acceptable if there is two seconds to three seconds

interva

ls between bubbles.

(3) Exce

ssive air bub bles in the fuel are not acceptable.

3. If excessive air is seen in the sight gauge in the

fuel ret

urn line, install a second sight gauge at

the inlet to the fuel transfer pump. If a second

sight gauge is not available, move the sight gauge

from the

fuel return line and install the sight gauge

at the inlet to the fuel transfer pump. Observe

the fuel ﬂow during engine cranking. Look for air

bubble

s in the fuel. If the engine starts, check for

air in the fuel at varying engine speeds.
