Cooling System

i02630833

Cooling System - Check

(Overheating)

SMCS Code: 1350-535

Above norm a l coolant temper atures can b e caused

by many conditions. Use the following procedure

to determine the cause of above normal coolant

temperatures:

Personal injury can result from escaping ﬂuid un-

der pressure.

If a pressure indication is shown on the indicator,

push the release valve in order to relieve pressure

before removing any hose from the radiator.

1. Check the coolant level in the cooling system.

Refer to Operation and Maintenance Manual,

“Cooling System Coolant Level - Check”. If the

coolant level is too low, a ir will g et into the cooling

system. Air in the cooling system will cause a

reduction in coolant ﬂ ow and bubbles in the

coolant. Air bubbles will keep coolant away from

the engine parts, which will prevent the transfer of

heat to the coolant. Low coolant level is caused by

leaks or inc orrectly ﬁlling the radia to r.

2. Check the mixture of antifreeze and water. The

mixture s hould be approximately 50 percent

water and 50 percent antifreeze with 3 to 6

percent coolant conditioner. Refer to Operation

and Maintenance Manual, “Reﬁll Capacities and

Recommendations”. If the coolant mixture is

incorrect, drain the system. Put the correct mixture

of water, antifreeze and coolant conditioner in the

cooling system.

3. Check for air in the cooling system. Air can enter

thecoolingsystemindifferentways.Themost

common caus es of air in the cooling syste m

are not ﬁlling the co o ling system correctly and

combustion gas leakage into the cooling system.

Combustion gas can get into the system through

inside cracks, a damaged cylinder head, or a

damaged cylinder head gasket. Air in the cooling

system causes a reduction in coolant ﬂow and

bubbles in the c oolant. Air bubbles keep coolant

away from the engine parts, which prevents the

transfer of heat to the coolant.

4. Check the fan clutch. A fan clutch that is not

turning at the correct speed can cause improper

air speed across the radiator core. The lack of

proper air ﬂow across the radiato r core can cause

the coolant not to cool to the proper temperature

differential.

5. Check the water temperature gauge. A water

temperature gauge which does not work correctly

will not show the correct temperature. Refer to

Testing and Ad ju sting, “Cooling S ystem - In sp ect”.

6. Check the sending unit. In some conditions, the

temperature sensor in the engine sends signals to

a sending unit. The sending unit converts these

signals to an electrical impulse which is used by a

mounted gauge. If the sending unit malfunctions,

the gauge can show an incorrect reading. Also if

the electric wire breaks or if the electric wire shorts

out, the gauge can show an incorrect reading.

7. Check the radiator.

a. Check the radiator for a restriction to coolant

ﬂow. Check the radiator for debris, dirt, or

deposits on the inside of the radiator core.

Debris, dirt, or deposits will restrict the ﬂow of

coolant through the radiator.

b. Check for debris or damage between the ﬁns

of the radiator core. Debris between the ﬁns of

the radiator core restricts air ﬂow through the

radiator core. Refer to Testing and Adjusting,

“Cooling Syste m - Inspect”.

c. Ensure that the radiator size is according to

the speciﬁcations of the Original Equipment

Manufacturer (OEM). An undersized radiator

does not have enough area for the effective

release of heat. This may cause the engine to

run at a temperature that is hig her than normal.

The normal temperature is dependent on the

ambient temperature.

8. Check the ﬁller cap. A pressure drop in the radiator

can cause the boiling p o int to be lower. This can

cause the cooling system to boil. Refer to Testing

and Adjusting, “Cooling S ystem - Test”.

9. Check the fan and/or the fan shroud.

a. The fan must be large enough to send air

through most of the area of the radiator

core. Ensure that the size of the fan and the

position of the fan are according to the O EM

speci

ﬁcations.

b. The fa n shroud must be the proper size and

the fan shroud must be positioned correctly.

Ensure that the size of the fan shroud and the

position of the fan shroud are according to the

OEM speciﬁcations.
