C27 and C32 Generator Set Engines Systems Operation Testing and Adjusting Page 44

Systems Operation Testing and Adjusting

Page of 68

/ 68

44 RENR9968-02

Testing and Adjusting Section

•

The oil suction tube has a leak or a restricted inlet

screen. Refer to Step 5.

•

The engine oil pump is faulty. Refer to Step 6.

•

Engine Bearings have excessive clearance. Refer

to Step 7.

1. Check t he engine oil level in the cran kcase. The

oil level can possibly be too far below the oil pump

supply tube. This will cause the oil pump not to

have th e ability t o supply enough lubrication to the

engine components. If the engine oil level is low

add engine oil in order to obtain the correct engine

oil level. Refer to Operation and Maintenance

Manual for the recommendations of engine oil.

2. Engine oil that is contaminated with fuel or coolant

will cause low engine oil pressure. High engine

oil level in the crankcase can be an indic ation

of contamination. Dete rmine the reason for

contamination of the engine oil and make the

necessary repairs. Replace the engine oil with

the approved grade of engine oil. Also replace

the engine o il ﬁlter. Refer to Operation and

Maintenance Manual for the recommendations of

engine o il.

NOTICE

Caterpillar oil ﬁlters are built to Caterpillar speci-

ﬁcations. Use of an oil ﬁlter not recommended by

Caterpillar could result in severe engin e damage to

the engine bearings, crankshaft, etc., as a result of

the larger waste particles from u n ﬁltered oil entering

the engine lu bricating system. Only use oil ﬁlters

recomm ended by Caterpillar.

3. If the engine oil bypass valves are held in the

open position, a reduction in the oil pressure can

be the result. This may be due to debris in the

engine oil. If the engine oil bypass valves are

stuck in the open position, remove each engine

oil bypass valve and clean each bypass valve in

order to c orrect this problem . You must also clean

each bypass valve bore. Install new engine oil

ﬁlters. Refer to the Disassembly and Assembly

manual for more information on servicing the

bypass valves.

4. An oil line or an oil passage that is open, broken,

or disconnected w ill cause low engine oil pressure.

An open lubrication system could be caused by a

piston cooling jet that is missing or damaged.

Note: The piston cooling jets dire ct engine oil toward

the bottom of the piston in order to cool the piston.

This also provid es lubrication for th e piston pin.

Breakage, a restriction, or incorrect installation of the

piston cooling jets will cause seizure of the piston.

5. The inlet screen of the oil suction tube for the

engine oil pump can have a restriction. This

restriction will cau se cavitation and a loss of

engine oil pressure. Check the inlet screen on

the oil pickup tube and remove any material that

may be restricting engine oil ﬂow. Low engine oil

pressure ma y also be the result of the oil pickup

tube that is drawing in air. Check the joints of the

oil pickup tube for cracks or a damaged O-ring

seal. Remove the engine oil pan in order to gain

access to the oil pickup tube and the oil screen.

Refer to Disassemb ly and Assembly, “En gin e O il

Pan - Remove and Install” for m o re informat ion.

6. Check the following problems that may occur to

the engine oil pump.

a. Air leakage in the supply side of the oil pump

will also cause cavitation and loss o f oil

pressure. Check the supply side of the oil pump

and make necessary repairs. For information

on the repair of the engine oil pump, refer to

Disassembly and Assembly, “Engine Oil Pump

- Remove”.

b. Oil pump gears that have too m uch wear will

cause a reduction in oil pressure. R epair the

engine oil pump. For information on the repair

of the engine oil pump, refer to Disassembly

and Assembly, “Engine Oil Pump - Remove”.

7. Excessive clearance at engine bearings will

cause low engine oil pressure. Check the

engine components that have excessive bearing

clearance and make the necessary repairs.

Reasons for High Engine Oil

Pressure

NOTICE

Keep all parts clean from contaminants.

Contaminants may cause rapid wear and shortened

component life.
