C27 and C32 Generator Set Engines Systems Operation Testing and Adjusting Page 5

Systems Operation Testing and Adjusting
RENR9968-02 5
Systems Operation Section
Starting the Engine
The engine’s ECM will automatically provide the
correct amount of f ue l in order t o start the engine.
Do not hold the throttle down while the engine is
cranking. If the engine fails to start in twenty seconds,
release th e starting sw itch . Allow the starting motor
to cool for two minutes before using the starting
motor again.
NOTICE
Excessive ether (starting fluid) can cause piston and
ring damage. Use ether for cold weather starting pur-
poses only.
Cold Mode Operation
The ECM will set the cold start strategy when the
coolant temperature is below 20 °C (68 °F).
When the cold start strategy is activated, low idle rpm
will be increased and engine power will be limited.
Cold mode operation will be deactivated when any of
the following conditions have been m et:
•
Coolant temperature reaches 20 °C (68 °F).
•
The engine has been running for twelve minutes.
Cold mode operation uses a modified control map,
that is stored in the ECM , in order to ad just th e fuel
injection timing and the injection duration for white
smoke cleanup. The engine will usually exit the cold
mode operation before the walk-around inspection
is completed. During cold mode operation, the
engine will remain at the elevated rpm that has been
specified for the engine.
After the cold mode is completed, the engine should
be operated at low rpm until normal operating
temperature is reached. The engine will reach normal
operating temperature faster when the engine is
operated at low rpm and low power demand.
Customer Specified Parameters
The engine is capable of being programmed for
several customer s peci fied parameters. For a brief
explanation of each of the customer specified
parameters, refer to the Operation and Maintenance
Manual for your engine.
