C27 and C32 Generator Set Engines Systems Operation Testing and Adjusting Page 62

Systems Operation Testing and Adjusting

Page of 68

/ 68

62 RENR9968-02

Testing and Adjusting Section

Electrical System

i02482495

Battery - Test

SMCS Code: 1401-081

Most of the tests of the electrical system can be done

ontheengine.Thewiringinsulationmustbeingood

condition. The wire and cable connections must be

clean, and both components must be tight.

Never disconnect any charging unit circuit or bat-

tery circuit cable from the battery when the charg-

ing unit is operated. A spark can cause an explo-

sion from the ﬂammable vapor mixture of hydro-

gen and oxygen that is released from the elec-

trolyte through the battery outlets. Injury to per-

sonnel can be the result.

The battery circuit is an electrical load on the charging

unit. The load is variable because of the condition of

the charge in the ba ttery.

NOTICE

The charging unit will be damaged if the connections

between the battery and the charging unit are broken

while the battery is being charge d . Damage occurs

because the load from the battery is lost and because

there is an increase in charging voltage. High voltage

will damage the charging unit, the regulator, and other

electrical components.

g00859857

Illustration 58

177-2330 Battery Analyzer

g00283565

Illustrati

on 59

4C-4911 Battery Load Tester

Use the 4C-4911 Battery Load Teste r or the

177-2330 Battery Analyzer in or der to test a battery

that does no

t maintain a charge when the battery

is active. Th e 4C-4911 Battery Load Tester and

the 177-2330 Battery Analyzer are portable units.

The 4C-491

1 Battery Load Tester or the 177-233 0

Battery Analyzer c an be used under ﬁeld conditions

and under high temperatures. The tester can be used

to load te

st all 6, 8, and 12 Volt batteries. Th is tester

has two heavy-duty load cables that can easily be

fastened to the battery terminals. A load adjustment

knob is lo

catedonthetopofthetester.Theload

adjustment knob permits the current that is being

drawn from the battery to be adjusted to a maximum

of 1000 a

mperes. The tester is cooled by an internal

fan that is automatically activated when a load is

applied.

Thetesterhasabuilt-inLCD.TheLCDisadigital

voltmeter. The LCD is a digital meter that will

also di

splay the amperage. The digital voltmeter

accurate ly measures the bat tery voltage at the battery

through wires fo r tracing. These wires are buried

inside

the load cables. The digital meter, that displays

the amperage, accurately displays the current that is

being drawn from the battery which is being tested.
