C27 and C32 Generator Set Engines Systems Operation Testing and Adjusting Page 31

Systems Operation Testing and Adjusting

Page of 68

/ 68

RENR9968-02 31

Testing and Adjusting Section

1. Determine if wat er a n d/ or c on taminants are

present in the fuel. Check the water separator (if

equipped). If a water separator is not present,

proceed to Step 2. Drain the water separator, if

necessary. A full fuel tank minimizes the potential

for overnight condensation.

Note: A water separator can appear to be full of fuel

when t he wate r separator is a ct ua lly full of water.

2. Determine if contaminants are present in the

fuel. Remove a sample of fuel from the bottom

of the fuel tank. Visually inspect the fuel sample

for contaminants. The color of the fuel is not

necessarily an indication of fuel quality. However,

fuel that is black, brown, and/or similar to sludge

can be an indication of the growth of bacteria or

oil contamination. In cold tempe r atures, cloudy

fuel indicates that the fuel may not be suitable

for operating conditions. The following methods

canbeusedtopreventwaxfromcloggingthefuel

ﬁlter:

•

Fuel heaters

•

Blending fuel with additives

•

Utilizing fuel w ith a low cloud point such as

kerosene

Refer to Operation and Maintenance Manual,

SEBU6251, “Caterpillar Com mercial Die se l

Engine Fluids Recommendations”, “Fuel

Recom mendations” for mo re information.

3. Check fuel API with a 9U-7840 Fluid and Fuel

Calibration Gp for low power complaints. The

acceptable range of the fuel API is 30 to 45 when

the API is measured at 15 °C (60 °F ), but there is

asigniﬁcant difference in energy within this range.

Refer to Tool Operating Manual, NEHS0607 for

API correction factors when a low power problem

is present and API is high.

Note: A correction factor that is greater than 1 may be

the cause of low power and/or poor fuel consumption.

4. If fuel qua lity is still suspected as a possible

cause to problems regarding engine performance,

disconnect the fuel inlet line, and temporarily

operate the engine from a separate source of

fuel that is known to be good. This will determine

if the problem is caused by fuel quality. If fuel

quality is determined to be the problem, drain the

fuel system and replace the fuel ﬁlters. Engine

performance can b e affected by the following

characteristics:

•

Cetane number of the fuel

•

Air in the fuel

•

Other fuel characteristics

i02285479

Fuel System - Prime

SMCS Code: 1258-548

The Secondary Fuel Filter Has

Been Replaced

Fuel leaked or spilled onto hot surfaces or elec-

trical components can cause a ﬁre. To help pre-

vent possible injury, turn the start switch off w hen

changing fu el ﬁlters or w ater separator elements.

Clean up fuel spills immediately.

NOTICE

Use a suitable container to catch any fuel that might

spill. Clean up any spilled f uel immediately.

NOTICE

Do not allow dirt to enter the fuel system. Thoroughly

clean the area around a fuel system component that

will be disconnected. Fit a suitable cover over discon-

nected fuel system component.

Note: Refer to Operation and Maintenance M anual,

“Fuel System Secondary Filter - Replace” for

information on replacing th e ﬁlter.

1. Turn the keyswitch to the “OFF” position.

2. Open the air purge screw for the fuel ﬁlter by three

full turns. Do not remove the a ir purge screw.

NOTICE

Do not crank the engine continuously for more than

30 seconds. Allow the starting motor to cool for two

minutes before cranking the engine again.

3. Start the engine. The engine should start and the

engine s hould run smoothly. If the engine does

not start after 30 seconds, allow the starter m otor

to cool for two minutes before attempting to start

the engine again.

Note: You may use the hand priming pump (if

equipped) for the fuel ﬁlter instead of starting the

engine and running the engine .

4. While the engine is running, observe the air purge

screw. When a small drop of fuel appears at the

threads of the air purge screw, close and tighten

the air purge screw.
