Note: There may be a noticeable change in the
sound of the running engine when the air purge
screw is tightened. The change in the sound of the
engine is normal.
Note: Failure to tighten all fittings could result in
serious fuel leaks.
5. Clean any residual fuel from the engine
components.
The Engine Has Been Run Out of
Fuel
NOTICE
Use a suitable container to catch any fuel that might
spill. Clean up any spilled fue l immediately.
NOTICE
Do not allow dirt to enter the fuel system. Thoroughly
clean the area around a fuel system component that
will be disconnected. Fit a suitable cover over discon-
nected fuel system component.
1. Turn the keyswitch to the “OFF” position.
2. Fill the fuel tank(s) with clean diesel fuel.
3. Bleed the air from the system by opening the fuel
pressure regulator valve by two turns and another
half turn.
Note: Do not remove the regulating valve completely.
Open the valve enough to allow the air that is trapped
in the cylinder head to be purged from the fuel
system.
NOTICE
Do not crank the engine continuously for more than
30 second s. Allow the starting motor to cool for two
minutes before cranking the engine again.
4. Crank the engine for 30 seconds. Use a suitable
container to catch the fuel while you crank the
engine. Allow the starter motor to cool for two
minutes.
Note: You may use the hand priming pump (if
equipped) for the fuel filter instead of cranking the
engine.
5. Crank the engine for 30 seconds. Allow the starter
motor to cool for two minutes.
6. Close and tighten the fuel pressure regulating
valve.
7. Crank the engine for 30 seconds. Allow the starter
motor to coo l for tw o minut es.
8. Repeat Step 7 until the engine starts and the
engine runs.
Note: Failure to tighten all fittings co uld result in
serious fuel leaks.
9. Clean any residual fuel from the engine
components.
The Engine Has Been Rebuilt
NOTICE
Use a suitable container to catch any fuel that might
spill. Clean up any spilled f uel immediately.
NOTICE
Do not allow dirt to enter the fuel system. Thoroughly
clean the area around a fuel system component that
will be disconnected. Fit a suitable cover over discon-
nected fuel system component.
1. Turn the keyswitch to the “OFF” position.
2. Fill the f ue l tan k(s) with c lea n d iesel fuel.
3. Open the air purge screw for the fuel filter by three
full turns. Do not remove the a ir purge screw.
4. Bleed the air from the s ystem by opening the fuel
pressure regulator valve by two turns and another
half turn.
Note: Do not remove the regulating valve completely.
Open the valve enough to allow the air that is trapped
in the cylinder head to be purged from the fuel
system.
NOTICE
Do not crank the engine continuously for more than
30 seconds. Allow the starting motor to cool for two
minutes before cranking the engine again.
5. Crank the engine for 30 s econds. Use a suitable
container to catch the fuel while you crank the
engine. Allow the starter motor to cool for two
minutes.
Note: You may use the hand priming pump (if
equipped) for the fuel filter instead of cranking the
engine.
6. Crank the engine for 30 seconds. Allow the starter
motor to coo l for tw o minut es.
