247, 257, 267, 277 and 287 Multi Terrain Loaders Operation and Maintenance Manual Page 16

Operation and Maintenance Manual
16 SEBU7494-06
Safety Section
Safety Messages
Work Tool Coupler (13)
This warning message is located inside the cab near
the hydraulic quick coupler control.
g00943149
Improper Attachment of the Work Tool could result
in injury or death.
Do not operate the machine without confirmation
that the coupler pins are fully engaged. Follow the
operating procedures in the Operation and Main-
tenance Manual.
Tilt the work tool downward.
Put down pressure on the work tool.
Move the machine backward. Ensure that the work
tool has not separated from the coupler assembly.
Machine Operation in Cold Weather
(14)
This warning message is located inside the cab on
the right side.
g00943150
The braking and steering system of this machine
react differently when the hydraulic oil is cold.
Operating the machine with cold hydraulic oil re-
quires extra stopping and turning clearances. Fail-
ure to follow the instructions or heed the warnings
could r esult in injury or death.
Refer to Operation and Maintenance Manual, “Engine
Starting” for information on machine preparation for
cold weather.
