Brace for the Loader Lift Arms (15)
This warning message is located on the brace for the
loader lift arms. The illustration may vary depending
on the machine that is being serviced. However, the
location of the label will remain unchanged.
g00943151
Loader lift arm brace must be in place when work-
ing under raised lift arms.
Failure to follow the instructions or heed the warn-
ings could result in injury or death.
Refer to Operation and Maintenance Manual, “Loader
Lift Arm Brace Operation” for operating information.
Aerosol S tarting Aid (16)
This warning message is located on top of the fuel
pump housing.
g00943154
Do not use aerosol types of starting aids such as
ether . Such use could result in an explosion and
person
al injury.
Pressurized System (17)
This warning message is located below the radiator
cap.
g00943155
Pressurized system: Hot coolant can cause seri-
ous burn. To open cap, stop e ngine, wait until ra-
diator is cool. Then loosen cap slowly to relieve
the pressure.
