247, 257, 267, 277 and 287 Multi Terrain Loaders Operation and Maintenance Manual Page 76

Operation and Maintenance Manual
76 SEBU7494-06
Operation Section
Operation
g00955964
Illustration 64
The “type 2” pin that is in the unlocked position (1) and the locked
position (2).
1. Put the fork tines in the Unlocked position. Space
the fork tines as far as possible from each other.
2. Put the fork tines in the Locked position.
3. Slowly, move the machine into position and
engage the load. The machine should be square
with the load. Space the forks evenly between the
pallet stringers.
4. Move the machine forward until the load contacts
the carriage.
5. Lift the load carefully.
6. Slowly, move the machine in reverse until the load
is clear enough to lower.
7. Carefully lower the load while you tilt the forks
back to the travel position.
Travel with the load as low as possible while you still
maintain ground clearance.
Travel with the load uphill on upgrades and on
downgrades.
i01871947
Work Tool Operation
SMCS Code
: 6700; 7000
The following tables describe the functionality of the
Auxiliar
y Hydraulic Control and the functionality of
the Fourth Function Control when you operate the
machine with approved Caterpillar hydromechanical
work tool
s.
While you opera
te the machine and the work tool
slowly in an open area, check for proper operation of
all controls and all protective devices on the machine
and the work to
ol.
g00793391
Illustration 65
joystick for the fourth function control (C1 and C2) and joystick for
the auxiliary hydraulic control (A1 and A2)
Note: For standard flow machines, use the A2
function in order to supply hydraulic oil flow to the
work tools that require continuous flow.
