247, 257, 267, 277 and 287 Multi Terrain Loaders Operation and Maintenance Manual Page 18

Operation and Maintenance Manual
18 SEBU7494-06
Safety Section
Safety Messages
Rollover Protective Structure/
Falling Object Protective Structure
(18)
Thiswarningmessageislocatedinsidethecabon
the upper left side.
g00943157
Structural damage, an overturn, modification, a l-
teration, or improper repair can impair this struc-
ture’s protection capability thereby voiding this
certification. Do not weld on or drill holes in the
structure. Consult a Caterpillar dealer to deter-
mine this structure’s limitations without voiding
its certification.
Crush Poi nt (19)
The warning messages that are shown are used
on the 257 Multi Terrain Loaders and the 277 Multi
Terrain Loaders. The messages are located near the
back of the machine on each side.
g00943160
No clearance for person in this area during oper-
ation. Severe injury or death from crushing could
occur. Stay away from the work tool while it is in
operation.
Multipurpose Bucket (20)
These warning messages are located on the front of
the multipurpose bucket.
g00943159
No clea
rance for person in this area during oper-
ation. Severe injury or death from crushing could
occur. Stay away from the work tool while it is in
operat
ion.
