Operation
(Table 14, contd)
OPERATION OF CATERPILLAR COMPLEX HYDROMECHANICAL WORK TOOLS
Position
of Fourth
Function
Control
Position of
Auxiliary
Hydraulic
Control
Work T ool
C2 C1
A1 A2
Results
X
If the sideshift control is in the PLANER position, the drum rotates
clockwise when you view the left side of the cold planer. If the sideshift
control is in the SIDESHIFT position, the cutting head will shift toward the
left side of the cold planer.
PC3 and PC4
Cold Planers
N/A
X
If the sideshift control is in the PLANER position, the cold planer does not
operate. If the sideshift control is i n the SIDESHIFT position, the cutting
head will shift toward the right side of the cold planer.
X
If the sideshift control is in the PLANER position, the drum rotates
clockwise
when you view the left side of the cold planer. If the sideshift
control is in the SIDESHIFT position, the cutting head will shift toward the
left side of the cold planer.
PC203 and
PC204 Cold
Planers
N/A
X
If the sideshift control is in the PLANER position, the cold planer does not
operate. If the sideshift control is i n the SIDESHIFT position, the cutting
head will shift toward the right side of the cold planer.
X The Hammer does not operate.
H63 H63S
Hammers
N/A
X The Hammer operates.
X
The cutting wheel rotates c ounterclockwise when you view the motor
side.
X X
The cutt
ing head angles to the left while the cutting wheel rotates. The
Auxiliary Electrical Control is in the ON position.
X
X The cutting head angles to the right while the cutting wheel rotates. The
Auxiliary Electrical Control is in the ON position.
X X
The cut
ting head retracts while the cutting wheel rotates. The Auxiliary
Electrical Control is in the OFF position.
X X
The cutting head extends while the cutting wheel rotates. The Auxiliary
Electrical Control is in the OFF position.
SG16 Stump
Grinder
X The wo
rk tool does not operate.
X
The auger rotates counterclockwise when you view the snowblower from
theleftsideofthemachine.
SR17
Snowblower,
SR18
Snowblower
and SR21
Snowblower
N/A
X
The auger rotates clockwise when you view the snowblower from the left
side of the machine.
(1)
The control is not applicable.
