Auxilia ry Electrical Control (If
Equipped) – The auxiliary electrical control
supplies cont
inuous electrical power to the
electrical harness that is located on the loader arm.
Press on the bottom of the switch in order to turn on
electrical p
ower. Press on the top of the switch in
order to turn off electrical power.
Plugged (25)
This space is not used on the machine. This space
may be used fo
r future functions.
Automatic Le
vel Control (26)
Automatic Level Control (If Equipped) –
The Automati
c Level Control maintains
the selected angle of the work tool as the
loader lift arms are raised. Press on the bottom of the
switch in or
der to activate the automatic level control.
Press on the top of the switch in order to deactivate
the automatic level control.
Continuous Flow and Interlock
Override (
27)
Machines that are equipped with Continuous Flow
and Interl
ock Override will support both functions
on one switch. Your machine may be equipped with
a switch that only supports the Interlock Override
function.
Continuous Flow (If Equipped) – The
contin uo
us flow control supplies continuous
flow of hydraulic fluid to the auxiliary
hydraulic circuit without continuously holding the
auxiliar
y hydraulic control. Press on either side of the
auxiliary hydraulic control. Press on the bottom of the
continuous flow switch and release the continuous
flow swi
tch. Immediately release the auxiliary
hydraulic control after you release the continuous
flow switch. The continuous flow function will not be
activat
ed if the operator does not release the auxiliary
hydraulic control within one second of releasing the
continuous flow switch. Press on either the auxiliary
hydrau
lic control or the continuous flow switch in
order to stop the flow to the auxiliary circuit.
Interlock Override (If Equipped) – The
interlock override function allows the
auxiliary hyd
raulic circuits to function with
the armrest in the RAISED position. First activate the
continuous flow function. If the machine is equipped
with a single
function switch then press the bottom of
the switch in order to activate the interlock override. If
the machine is equipped with a dual function switch
then press t
he top of the switch in order to activate
the interlock override function. In order to turn off
the interlock override function and continuous flow
function, p
ress either side of the auxiliary hydraulic
switch or Interlock Override switch.
NOTICE
Do not leave the machine unattended while you have
the interlock override function activated.
Rear Auxiliary Hydraulic Control or
Fourth Function Control (28)
g00902830
Illustration 43
g009028
34
Illustration 44
