"C" SERIES SKID STEER LOADERS Service Training Meeting Guide Page 63

Service Training Meeting Guide
The hydrostatic motor requires an oil change after the first 250 service hours and every
subsequent 500 service hours.
The roller frame assembly (4) supports the front and rear idler wheels (5) and the
bogie wheels (6).
The tensioner (7) allows adjustment of the track tension. As the hydrostatic piston motor
support structure (drive table) (8) rotates, the drive sprocket group rotates engaging the triple
row of lugs on the track (9).
An extra (third) row of drive lugs and an extra (third) row of rollers has been added to the
sprocket assembly on the "C" Series machines. Also, a extra (fourth) row of bogie wheels has
been added to the "C" Series machines
Grease fittings (10) (2 front/2 rear) are located on the front and rear torsion axle tubes of the
undercarriage.
Note: Grease fittings are located at the front and at the rear of both the DLS and SLS
undercarriage. Not all grease fittings are visible in the illustrations.
The undercarriage area is more open which aids cleaning and does not retain dirt and debris
SERV1833-01 - 63 - Text Reference
07/08
