"C" SERIES SKID STEER LOADERS Service Training Meeting Guide Page 79

Service Training Meeting Guide
If the work tool control lever is only partially shifted, some pump supply oil is metered through
the center of the lift valve to the next circuit and then to the tank (unless one of the other
control valves is fully shifted).
If the lift circuit is stalled in either direction, no oil returns from the lift cylinders to become
supply oil for the tilt circuit. If the lift control spool is fully shifted, there will also be no oil
metered to the tilt circuit. The tilt circuit will not function until the pilot valve for the lift
circuit is moved from the fully shifted position.
NOTE: Supply oil to the tilt and auxiliary circuits are shown in pink and red stripes to
reflect that the lift control valve is of a series flow design.
SERV1833-01 - 79 - Text Reference
07/08
