Caterpillar Customer Communication Module PC Page 104

Getting Started
14-2
Step 2 Select the Show Tool Bar check box to display the
pushbuttons on the Cat CCM PC toolbar.
Step 3 To select the communication (COM) port that you are
connected to, check the COM 1, COM 2, COM 3, or
COM 4 radio button under the Ports section. The COM
port radio button that you select must be the same as
the COM port connection on the back of your PC.
Step 4 Press the “International…” pushbutton, displaying the
Regional Settings Properties dialog box, to make
international PC adjustments. The standard Microsoft
Windows International dialog box displays. See the
Microsoft guide for help with this dialog box.
Note: The Number tab in the Regional Settings Properties dialog box
is where you change the Measurement system between U.S. and
Metric.
