Caterpillar Customer Communication Module PC Page 72

Getting Started
9-14
Available ECMs List Box
The Available ECMs list box displays the description of each ECM on
the data link. The ECMs are listed alphabetically. The highlighted
ECM is the one that is currently selected. You can only select one
ECM at a time.
Data Area
The ECM summary data area is located in the center of the screen. It
displays a summary of descriptive parameters that identify the
currently selected ECM. The left side of this area displays the
parameter name, and the right side displays the data information for
each parameter.
Cat CCM PC Information Area
The Cat CCM PC information area is located on the right of the
screen. It displays the Cat CCM PC software version, serial number,
and subscription information.
Pushbuttons
The pushbutton available in the ECM Summary screen is:
•= Print
Note: See “Printing a Document” section 6.
