Caterpillar Customer Communication Module PC Page 61

Getting Started
9-3
Section
9
Note: Using the ↑ and ↓ keys, you can consecutively view each
group and its parameters in the Select Group dialog box. If a group is
created, you can choose that group by selecting the first letter of its
name.
Step 2 Press “OK” to accept the selected group. The group data
that you selected displays in the Status screen.
Press “Cancel” to leave this screen without choosing a
group.
Note: In the Status dialog box, you can view each group
consecutively by using the “Page Up” and “Page Down” keys. You
can view a specific default group by selecting the key number
corresponding to that Group.
Screen Layout
The Status screen has the following areas:
Status Flag Area:
Cat CCM PC displays up to four Status Flag indicators across the
top of the screen. These flags are used to notify you of currently
active conditions, such as Low Oil Pressure, Engine Overspeed, etc.
When a warning condition exists, it is described in the appropriate
flag indicator area. The name of the active ECM displays above the
flags.
ECM Title Area
The ECM title area displays the ECM group and ECM name that you
have chosen. This area is located in the upper left-hand corner of the
screen below the Status Flags.
Display Area
The Status display area is located in the center of the screen. It
displays the values, units, and descriptions of the ECM parameters
for the group you have chosen. When a parameter is not supported
by the current ECM, or if an error occurred while reading the data,
the word “Unavailable” displays.
Pushbuttons
The following pushbuttons are available in the Status screen:
•= Groups…
•= More
•= Zoom In/Zoom Out
•= Hold/Resume
