Caterpillar Customer Communication Module PC Page 85

Getting Started
11-3
Section
11
Step 4 Select the Bits Per Second (BPS) in the BPS drop-down
list. The BPS rate needs to match the baud rate of the
CCM in the Direct connection and the BPS needs to
match the baud rate of the connected modem in the
Modem connection.
Step 5 Select the serial port in the Com Port drop-down list.
Step 6 Press the radio button for the desired Parity.
Step 7 Press the radio button for the desired Data Bits.
Step 8 Press the radio button for the desired Stop Bits.
Note: The Baud Rate, Stop Bits, Data Bits, and Parity must be set to
match what is configured for the CCM in the CCM Configuration tool.
Step 9 Select tone or pulse from the Dial Type drop-down list.
Step 10 If the Modem requires a special initialization before the
telephone number is dialed, up to 50 characters can be
entered in the Modem Init Spring text box. These
characters are sent to the modem just ahead of the
telephone numbers.
Step 11 Enter the sites telephone number to dial (up to 50
characters) in the Phone Number text box.
Step 12 Press “OK” to add the site description. Press “Cancel” to
exit the setup. You will return to the Phone Book dialog
box.
Perform the following steps to edit an existing site:
Step 1 Select the site you want to edit from the Phone Book
dialog box.
Step 2 Press the “Edit…” pushbutton. The Edit Site dialog box
displays.
