Caterpillar Customer Communication Module PC Page 24

Getting Started
5-4
WARNING! You must remember your CCM Security Level 3
password. If you forget your password, you must replace your
CCM.
Illustration 5-5: ECM Selector dialog box
Note: The CCM ECM is not displayed in the ECM Selector box when
you initially connect to Cat CCM PC. To display the ECM, select the
Select ECM from the Data Link Menu. The ECM Selector dialog box
displays with the available ECMs.
Step 4 Select an ECM and press “OK.” When the data is
loaded, the ECM Summary dialog box displays.
Press “Cancel” to exit the ECM Selector dialog box, thus
leaving Cat CCM PC in a disconnected state. Press
“Help” to open online help for assistance.
Illustration 5-6: ECM Summary screen
